Actuators & Accessories

Series 25 Pneumatic Scotch Yoke


  • Rated torque to 240,101 inch/lbs (27,128 Nm)
  • Features

    • Hard anodized, extruded aluminum body
    • High strength alloy, ENP coated pinion gear
    • SS end cap bolts
    • Bi-directional adjustable external travel stops (± 5º in both open and closed directions)
    • Unique patented insert design offers Double D, ISO square, round end keyed; can direct mount to many quarter turn valve designs
    • Guide bar in pistons provide inherent blowout proof design
